EN 10357 13mm OD Polished Sanitary Hygienic Tube Food Grade

Very competitive price and the tubes are well polished, we are very satisfied with Spezilla from our cooperation since year 2010.

—— Nathalie Gulli - Mexico

Spezilla supports our group very well, and now we are approved supplier of goverment, they are reliable and flexible! Spezilla always answers!

—— Jaime Arias - Argentina

Good quality, fast delivery, Spezilla has been supplying heat exchanger tubes for our projects since 2008, we really appreciate your support!

—— Massimiliano Rossi - Italy

I'm Online Chat Now

EN 10357 13mm OD Polished Sanitary Hygienic Tube Food Grade

EN 10357  13mm OD Polished Sanitary Hygienic Tube Food Grade
EN 10357  13mm OD Polished Sanitary Hygienic Tube Food Grade

Large Image :  EN 10357 13mm OD Polished Sanitary Hygienic Tube Food Grade

Product Details:
Place of Origin: KOREA / CHINA
Brand Name: SPEZILLA
Certification: 3A ISO9001
Model Number: 13 X 1.5 X 6000MM
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: negotiable
Packaging Details: WOODEN BOXED
Delivery Time: 5-8 WORKING DAYS
Detailed Product Description
Material: 1.4301 Specification: EN10357 / DIN 11850
OD: 13.00MM WT: 1.50MMM
Length: 6000MM Finish: Polished
High Light:

EN 10357 hygienic tube

,

13mm hygienic tube

,

EN 10357 sanitary tubing

EN 10357 13 X 1.5MM 1.4301 Polished Stainless Steel Sanitary Tubing, Welded, 6M Length

Features:


Spezilla offers EN10217-7 DIN 11850 / EN 10357 welded stainless steel sanitary tubings from DN10 to DN200, with materials grade stainless steel 1.4301, 1.4307, 1.4404 etc. DIN EN 10357 was developed for seam welded tubes made of stainless steel for pipeline systems in the food, pharmaceutical and chemical industries. DIN EN 10357 (2014-3) replaces DIN 11850 at the beginning of 2014. Fundamental changes to DIN 11850: - Tube series 1 and 2 have been replaced and supplemented by series A to D. - Series A replaces DIN series 2, series B replaces DIN series 1, series C corresponds to ISO and series D corresponds to OD and SMS.



Materials: 1.4301, 1.4307, 1.4404



Type:        Welded



Standards: EN10217-7 DIN 11850 EN10357



Surface Finish: CC, CD, BC, BD



Descriptions:


Item Code: SPW-EN10357-A-4301-0013-0150
Tube OD.: 13.00MM
Wall: 1.50MM
Length: 6000MM
Material: 1.4301
Standard: EN10357 Series A  (DIN 11850 Reihe 2)
Finish: CC, CD, BC, BD
Polish: Mechanical Polished
Type: Welded
Certification: 3A - Food / Dairy Grade
Mill Test Certificate: EN10204 3.1
Packing: Sleeved, Ends Capped, Wooden Boxed


Chemical Compositions:


Elements 1.4301 (wt%)
C / Max. 0.07
Mn / Max 2.00
P / Max 0.045
S / Max 0.030
Si / Max 1.00
Ni  8.00 - 10.50
Cr 17.00 - 19.50
Mo N/A
Fe Bal.
Cu N/A
N 0.11



Mechanical Properties:



Grade

Tensile Strength
(Mpa)

Yield Strength
 (Mpa)

Elongation
(%)


 1.4301



500 - 700


≥195


≥40





Quality Assurance:



Spezilla's EN10217-7 DIN 11850 / EN10357 welded stainless steel sanitary tubing undergoes a rigorous quality inspection, including destructive and non-destructive examination, at the mill prior to shipment.



1. Chemical Composition: PMI Test



2. Mechanical Properties: Tensile Test, Hardsness Test


3. 100% Eddy Current, Air Under Water Test,  Hydrostatic Test


4. Flange Test, Flattening Test, Reverse Flattening Test, Reverse Bending Test.



5. Dimensional Check: OD, WT, Straightness


6. Metallurgical Test



Applications:


Spezilla's EN10217-7 DIN 11850 EN 10357 welded stainless steel sanitary tubings are applicable to a wide range of manufacturing industries as following:


1. Food Processing & Beverage


2. Dairy


3. Wine & Brewery


4. Cosmetic



5. Biotechnolgy, Pharmaceutical
