EFW 2507 super duplex stainless steel,Round Mechanical Tubing UNS S32750 A928M

EFW 2507 super duplex stainless steel,Round Mechanical Tubing UNS S32750 A928M​

Characteristics:

Grade 2507 is a Molybdenum and Nitrogen alloyed Super-Duplex stainless steel with corrosion resistance
in-line with the 6 Mo grades (e.g. 254 SMO®), and with a yield strength more than double that of austenitic stainless steels. It is also the strongest Duplex in welded tubular products.

Characteristic properties:

• High mechanical strength

• Good weldability

• Good corrosion resistance

• High resistance to Stress Corrosion Cracking (SCC)

• Good machinability

• Very good wear and abrasive resistance

• Low thermal expansion

• Good fatigue properties

• Temperature range -40°C to 250°C

Dimensions:

2507 is considered a stock standard material for OSTP in selected production standards and dimension ranges.

Tubes, Pipes and Butt Weld Fittings

• OD: 21.3–1219.0 mm

• WT: 1.5–25.4 mm

• Lengths: up to 12 m

Tubes below 21.3 mm OD and tubes with wall thickness below 1.5 mm or length over 12 m on special request.

Standard Stock Dimension Range:

• ANSI NPS 6–12" Sch 10S, ASTM A928 Class 3

• Fittings according to ASTM A815

Executions:

Tubes, Pipes and Butt Weld Fittings

• Welded with- or without filler metal

• Unannealed, pickled

• Solution annealed and pickled

• With – or Without BCW (Bead Cold Work)

– Tubes Only

• Bevelled ends according to standards
