Welded Annealed custom steel tubing,Round Mechanical Tubing 1/2 - 8 Inch

Welded Annealed custom steel tubing,Round Mechanical Tubing 1/2 - 8 Inch
Welded Annealed custom steel tubing,Round Mechanical Tubing 1/2 - 8 Inch Welded Annealed custom steel tubing,Round Mechanical Tubing 1/2 - 8 Inch Welded Annealed custom steel tubing,Round Mechanical Tubing 1/2 - 8 Inch Welded Annealed custom steel tubing,Round Mechanical Tubing 1/2 - 8 Inch

Large Image :  Welded Annealed custom steel tubing,Round Mechanical Tubing 1/2 - 8 Inch

Product Details:
Place of Origin: CHINA
Brand Name: SPEZILLA
Certification: ASME BPE
Model Number: 1/2''-8''
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: WOODEN BOX PACKING
Delivery Time: 5-8 WORK DAYS
Payment Terms: L/C, T/T
Supply Ability: 1000TONS/MONTH
Detailed Product Description
Product Name: Stainless Steel Tubing Tech Specs: ASTM A270
Material Type: 304, 304L, 316L Manufacturing: WELDED, OD/ID POLISHED
Polish: MECHANICAL POLISH Dimention: 1/2'' - 8''
Documentation: EN10204 3.1 Shape: Round
Package: Wooden Case Application: Food
High Light:

round mechanical tubing

,

stainless steel round tube

Welded Annealed custom steel tubing,Round Mechanical Tubing 1/2 - 8 Inch





Description:



Spezilla's reputation for cleanliness and surface finish of welded stainless steel sanitary tube, combined with quality of service have made Spezilla's tubes an accepted standard in the sanitary, dairy, food, beverage and pharmaceutical industries.

Spezilla maintains a large inventory of welded stainless steel sanitary tube to meet your immediate needs. Our warehouse is able to quickly ship welded stainless steel sanitary tube in lengths up to 20 feet. Each tube order is processed promptly and packaged in tri-wall corrugated cartons equipped with wooded ends to protect each piece from damage.

Materials:

Welded stainless steel sanitary tube types 304/304L and 316/316L are available in sizes from 1/2" OD - 8" OD produced to ASTM specifications A249, A269, A270 or A778. Other diameters, specifications and lengths are available on special order. Finishes available range from Bright Annealed (mill) to 240 grit mechanical ID and OD.


Mechanical Tests:


To ensure the highest surface quality in all of our welded stainless steel sanitary tube, Spezilla routinely go beyond the requirements of ASTM A269 and A270 by performing the full battery of ASTM bend and deformation tests required by ASME SA249 as well as additional deformation tests developed by Spezilla. The tests, combined with specific raw material requirements, eddy current testing at the tube mill, 100% bore-scoping prior to mechanical polish, and tighter OD and wall tolerances allow us to provide a more consistent superior quality product to the marketplace.


Annealing:


Hydrogen bright annealed in line to 1900°F (1040°C) minimum and rapidly quenched.


Surface Finish:


Surface finish is 20 µ-in Ra (0.5 µm) ID maximum, 30 µ-in Ra (0.8 µm) OD maximum measured per ASME/ANSI B46.1 with the profilometer reading at 90 degrees to major polishing pattern.



Testing & Packaging:



To assure strict accordance with ASTM A270, Spezilla welded stainless steel sanitary tube is subjected to extensive reverse bend, reverse flattening, flange, and eddy current testing. After successfully completing testing, tubes are sealed with air tight end caps and individually packaged in high quality poly sleeves. Tubes are then packaged in heavy-duty tri-wall boxing. Wood boxes are available for export shipments when specified.



Specifications:



Stainless Steel Sanitary Tube Specifications
O.D. WALL THICKNESS STOCK LENGTHS
1/2'' 0.065'' 20'
3/4'' 0.065'' 20'
1'' 0.049'' 20'
1'' 0.065'' 20'
11/2'' 0.049'' 20'
11/2''

0.065''

20'
2'' 0.049'' 20'
2'' 0.065'' 20'
21/2'' 0.065'' 20'
3'' 0.065'' 20'
4'' 0.065'' 20'
4'' 0.083'' 20'
6'' 0.083'' 20'
6'' 0.109'' 20'
8''

0.109''

20'
10'' 0.134'' 20'
12'' 0.134'' 20'
14'' 0.134'' 20'



Chemical Composition % Max. Stainless Steel Sanitary Tube
TYPE C Mn P S Si Ni Cr Mo
304L 0.030 2.000 0.045 0.030 0.750 8.00-12.00 18.00-20.00 N/A
316L 0.030 2.000 0.045 0.030 0.750 10.00-14.00 16.00-18.00 2.00-3.00



Applications:



1. Beverage/Brewery, Food & Dairy



2. Pharmaceutical/Biopharmaceutical



Spezilla is a global supplier of stainless steel sanitary tube for the Brewery, Food, Dairy and Pharmaceutical Industries. Spezilla offers tubes from ½” to 8” OD in 304L & 316L polished on the ID to 20u-in Ra/OD to 30u-in Ra.
